10 Technical Specifications
Dimensions (W x H x D) 400 x 360 x 650
Melting frequency 60 kHz
Weight 38 kg
Noise level 65 dB (A)
Quantities min. 15 g, max.110g noble metal / approx.55 g non-precious
metal
Muffle size 1 to 9 and model casting muffles
Casting material noble metal / non-precious metal
Casting time (dependent on
alloy)
60 to 180 sec.
Vacuum approx. 90 – 93 %
Heating Induction
Sequence of operation Manually with step switch
Number of memory cells 1/ max.4
Chamber pressure max. 3 bar
Housing stainless steel
approx. 6 to 7 l / casting
Air connection 5-6 bar
Protective gas connection Argon- bottle pressure 5-6 bar
Water connection a) in circulation with pump (accessories)
b) Water supply min. 3 – 4 bar
Power supply 16 AC 230 V 50 / 60 Hz
(functional disorder if tension is below 215 V)
Fuse 16 A delayed action fuse or protect switch K16A or C16A
(no further consumers connected to the 16A-fuse)
Max. temperature 1600 °C
Cas
