7 Commissioning and Operation
7.5 Adjusting the jet geometry
Note!
Thegunhasavariablejetgeometrytoproducearoundoratspraypattern.
Youshouldonlyworkwithclean,dry,ltered,oil-freeair.
 1. Selectasuitableairap.
2. Position the air distributing ring to produce
the desired jet geometry.
3. Make the appropriate setting for the atomiser air.
4. Make the appropriate setting for the horn air.
7.5.1 Distance to workpiece
Positon the automatic gun AGR-08-E about 15 to 30 cm from the workpiece.
Position
for vertical
spray pattern
Position
for horizontal
spray pattern
