REITER AGR-08-E - Maintenance; Required tools and lubricants; Removing gun

S-AGR08-Egb08 05/15 - 3 Page 1 of 15
8 Maintenance
Note: The air cap can be replaced on the automatic spray gun AGR-08-E without removing it from
the system.
For all other maintenance jobs, the automatic spray gun AGR-08-E must be removed from the in-
termediate plate/adapter and replaced by a reserve gun.
8.1 Required tools and lubricants
The following are required for installation and removal:
 • Socketwrenchornut,size13
 • Hexagonsocketheadwrench,size4andsize6
 • TorxwrenchTO40
 • Torquewrench
 • Gungrease(partno.65026530)forwettingoftheo-ringwhenplacingthegun
Note: Needle,needlesetandpistonshouldonlybeexposedtogungrease(partno.65026530).
OthergreasecanleadtoamalfunctionoftheautomaticspraygunAGR-08-E(unsuitablegrease
couldcauseswellingofneedlesetandpiston).
8.2 Removing gun
Caution!
Danger of injury due to lines under pressure!
• WhenremovingtheautomaticspraygunAGR-08-E,sprayuid
may emerge under high pressure.
• Makecertainnopaintmaterialgetsintotheairchannels.
Rinse and blow out the material lines, then depressurise them.
Wearprotectiveclothingand/orglasses.
1. Loosen stud on intermediate plate
 2. RemovingautomaticgunAGR-08-Eup.
!
Table of Contents
8.1 Required tools and lubricants ............................................................................................1
8.2 Removinggun ....................................................................................................................1
8.3 Dismantling of the automatic gun.......................................................................................2
8.4 Reassemblyoftheautomaticgun......................................................................................6
8.4.1 Possiblesourcesoferrorforthereassembly...................................................................10
8.5 Maintenanceofneedleset ............................................................................................... 11
8.6 AssemblydeviceforsprayingsystemAGR-08(option) ...................................................13
8.7 Faults ...............................................................................................................................14
