STT293 CONCISE TOWER CRANE MANUAL
-18- EURC1.0ENG
1.2. PREPARING THE CONSTRUCTION SITE
1.2.1. SPACE REQUIREMENTS FOR ASSEMBLY
1.2.1.1. INTRODUCTION
This brochure provides the dimensions of the space requirements for the crane.
They consist of two sets:
- The entire crane with indication of the most important dimensions.
- The crane is shown in three parts:
Foundation anchors and undercarriage
Mast composition
Range and jib length
Based on the provided dimensions, you can prepare the assembly of the crane.
ATTENTION: The provided dimensions do not take account of sagging
under load or any manufacturing tolerances.
