STT293 CONCISE TOWER CRANE MANUAL
-34- EURC1.0ENG
1.3.2. INSTALLATING THE CRANE FOUNDATION
The foundation anchors are mounted by means of:
4 foundation anchors and 8 associated pins
1 foundation framework and 8 associated pins
1 standard mast section
1 plumb line or measuring device
- Check the framework for any deformation during transport. The difference
between respectively the diagonals and the bearing surface heights may be
at the most 2 mm.
- Install the foundation anchor on the reinforcement and adjust by means of
filling plates.
- Check perpendicularity in both directions after assembly of the lower mast
section on the framework. Adjust if necessary.
- Pour the concrete block and wait until it is completely hardened before
removing the mast section and the framework
