STT293 CONCISE TOWER CRANE MANUAL
62- EURC1.0ENG



 

4.1. SYMBOLS
DFV ᧤EX. 7.5DFV08᧥
ATTENTION: The trolley speed must be selected according to the
distance to be run. Increase and decrease speeds
gradually.
Composition of the trolley winch
Fig 4.1-1
1. Outside support board
2. Reductor
3. Drum
4. Motor
5. Limiter
6. Brake
1
Couple
Frequency controlled
Motor capacity (HP)
! !
