STT293 CONCISE TOWER CRANE MANUAL
-36- EURC1.0ENG
1.3.3.2. CONFIGURATION MAST LENGTH 5500MM-L69S MAST
t
Torsional moment(kN.m)
v
Overturning moment(kN.m)
P Weight of crane(kN)
Fh Horizontal reaction(kN)
Q Mass of foundation concrete(kN)
e excentricity(m)
p
B
Pressure on ground(kN/m
2
)
[p
B
] Permissible ground pressure(kN/m
2
)
L Max.hook radius
H Hook height
n Number of section
A number
IN SERVICE OUT OF SERVICE
L(m) L(m)
H
(m)
n
74 70 64 60 54 50 44 40 74 70 64 60 54 50 44 40
Mv
4193 4033 4042 3927 3866 3878 4132 4157 5958 5663 5255 5218 4934 4814 4474 4376
Fh
42 42 42 41 41 40 40 40 159 158 157 156 153 152 150 150
63.1 11
P
1067 1064 1050 1032 997 989 1001 988 947 944 930 912 877 869 881 868
Mv
3892 3736 3746 3635 3578 3591 3843 3869 4913 4626 4232 4200 3938 3824 3498 3406
Fh
39 39 39 39 38 38 37 37 147 146 145 144 141 140 139 138
57.6 10
P
1034 1031 1017 999 964 956 968 954 914 911 897 879 844 836 848 834
Mv
3620 3466 3478 3369 3317 3331 3582 3608 3970 3691 3309 3282 3041 2934 2621 2534
Fh
37 37 36 36 35 35 35 35 135 135 133 133 129 129 127 126
52.1 9
P
1001 998 984 965 931 923 934 921 881 878 864 845 811 803 814 801
Mv
3373 3222 3236 3129 3081 3097 3346 3373 3121 2850 2480 2458 2238 2136 1837 1786
Fh
34 34 34 33 33 33 32 32 124 123 121 121 118 117 115 115
46.6 8
P
968 965 951 932 898 889 901 888 848 845 831 812 778 769 781 768
Mv
3151 3002 3018 2913 2870 2886 3135 3163 2362 2098 1740 1722 1522 1533 1742 1786
Fh
31 31 31 31 30 30 29 29 112 111 110 109 106 105 104 103
41.1 7
P
934 931 917 899 864 856 868 855 814 811 797 779 744 736 748 735
Mv
2952 2805 2823 2719 2681 2698 2947 2975 1688 1430 1426 1413 1471 1533 1742 1786
Fh
29 29 28 28 27 27 27 27 100 99 98 97 94 93 92 91
35.6 6
P
901 898 884 866 831 823 835 821 781 778 764 746 711 703 715 701
Mv
2775 2631 2649 2548 2514 2532 2781 2809 1092 1139 1426 1413 1471 1533 1742 1786
Fh
26 26 26 25 25 25 24 24 88 88 85 86 83 82 80 79
30.1 5
P
868 865 851 832 798 790 801 788 748 745 731 712 678 670 681 668
Mv
2619 2477 2497 2397 2368 2368 2635 2665 914 1139 1426 1413 1471 1533 1742 1786
Fh
23 23 23 23 22 22 21 21 77 76 75 74 71 70 68 68
24.6 4
P
835 832 818 799 765 756 768 755 715 712 698 679 645 636 648 635
Mt
500 500 500 500 500 500 500 500 0 0 0 0 0 0 0 0
3
b
FF
h FM
e
gv
hv
d



>@
B
gv
B
p
bl
FF
p d

3
)( 2
K
O
E
H
)J
)Y
)K
0Y
! !
