1.2.2.2.5. Mast
Mast section Connecting anchor Resting platform
Short ladder Long ladder Ladder support
Fig 1.2.2.2.5-1
NOTE: The ladder sections (main mast) must be modified if 5500-mm
mast lengths are used.
