24
REPREP
REPREP
REP
AIR PAIR P
AIR PAIR P
AIR P
ARTSARTS
ARTSARTS
ARTS
Table Top Electric
KEY
NO. PART DESCRIPTION
1 Access Panel (ea.)
2 Dip Tube
3 Drain Access Door
4 Drain Valve
5 Element Gasket
6 Element w/Gasket
7 Lower Thermostat
8 Lower Thermostat w/High Limit
9 Porcelain Top
10 Primary Anode Rod
11 T&P Valve
12 Terminal Cover
13 Terminal Cover
14 Thermostat Bracket (ea.)
15 Toe Panel
16 Upper Thermostat w/High Limit
The following parts may be ordered through the store you purchased
the water heater from, or direct from the factory.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will be
shipped at prevailing prices and you will be billed accordingly.
The model number of your Electric Water Heater will be found on the
model rating plate located above the lower access panel.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING
INFORMATION:
• MODEL NUMBER
• SERIAL NUMBER
• VOLTAGE AND ELEMENT WATTAGE
• PART DESCRIPTION
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
