Reloop MIXAGE Interface Edition User Manual

ENGLISH
24
INSTRUCTION MANUAL
CAUTION!
For your own safety, please read this operation manual carefully before initial operation! All per-
sons involved in the installation, setting-up, operation, maintenance and service of this device
must be appropriately qualied and observe this operation manual in detail. This product complies
with the requirements of the applicable European and national regulations. Conformity has been
proven. The respective statements and documents are deposited at the manufacturer.
INDEX
1. Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.1. Control Elements & Connections. . . . . . . . . . . . . 27
2. Initial Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3. Computer Conguration . . . . . . . . . . . . . . . . . . . . . . . . 28
3.1. ASIO Driver Installation . . . . . . . . . . . . . . . . . . . . 28-29
3.2. Traktor LE Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.2.1. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.2.2. Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31
3.3. Audio-Setup & Mapping Import . . . . . . . . . . . . . . 32
3.3.1. Audio-Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32-33
3.3.2.Mapping-Import (only Traktor Pro) . . . . . . . . . . . 33-35
4. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35-37
5. Device Settings and Tests. . . . . . . . . . . . . . . . . . . . . . . 37
5.1. MIDI Channel Assignment. . . . . . . . . . . . . . . . . . . 37
5.2. LED Function Test . . . . . . . . . . . . . . . . . . . . . . . . . 38
6. Updates & Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.1 Firmware-Check. . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.2. Firware-Update . . . . . . . . . . . . . . . . . . . . . . . . . . . 38-40
7. Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.1. System Requirements Traktor LE . . . . . . . . . . . . 40
7.2. MIDI Assignment Chart. . . . . . . . . . . . . . . . . . . . . 40-42
7.3. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.4. Technical Specications . . . . . . . . . . . . . . . . . . . . 44
Congratulations on purchasing the Reloop Mixage Interface Edition. Thank you for placing your trust
in our disc jockey technology. Before operating this equipment we ask you to carefully study and
observe all instructions.
Please remove the Reloop Mixage Interface Edition from its packaging. Before initial operation
please make sure that the device has not been visibly damaged during transport. If you detect any
damage to the power cable or the casing, do not operate the device and contact your specialised
dealer.
SAFETY INSTRUCTIONS
CAUTION!
Please exercise particular caution when handling the power voltage. This voltage rating may lead
to a critical electrical shock! Any damage caused by the non-observance of this operation manual
excludes any warranty claims. The manufacturer is not liable for any damage to property or for
personal injury caused by improper handling or non-observance of the safety instructions.
- This device has left the factory in perfect condition. To maintain this condition and to ensure a
risk-free operation the user must observe the safety instructions and warnings contained in this
operation manual.
- For reasons of safety and certication (CE) the unauthorised conversion and/or modication of the
device is prohibited. Please note that in the event of damage caused by the manual modication to
this device any warrantyclaims are excluded.
