ENGLISH
27
1.1 CONTROL ELEMENTS & CONNECTIONS
Surface
T1.
. . . . . .Pitch Bend – Button
T2.
. . . . . .Pitch Bend + Button
T3.
. . . . . .Shift Button
T4.
. . . . . .Autoloop Button (Shift: Loop In)
T5.
. . . . . .Loop Length -/+ (Shift: Beat Move > only Traktor Pro)
T6.
. . . . . .Gain Dial
T7.
. . . . . .Pitchfader incl. Status LED Indicator (illuminated at 0%)
T8.
. . . . . .Reloop Button (Shift: Loop Out)
T9.
. . . . . .FX Select Button (Shift: Master Deck Assignment)
T10.
. . . . .FX Dry/Wet + Dial (Shift: Pan Balance Dial)
T11.
. . . . . .Amount (FX Parameter 1) Dial (Shift: Filter)
T12. . . . . .FX On Button (Shift: Keylock Button)
T13.
. . . . .Search Mode Button
T14.
. . . . .Scratch Mode Button
T15.
. . . . .Jog Wheel
T16.
. . . . .Sync Button (Shift: Cue 1 > only Traktor Pro)
T17.
. . . . .Cup Button (Shift: Cue 2 > only Traktor Pro)
T18.
. . . . .Cue Button (Shift: Cue 3 > only Traktor Pro)
T19.
. . . . .Play/Pause Button (Shift: Cue 4 > only Traktor Pro)
T20.
. . . .Trax Encoder (Shift: Folder Navigation)
T21. . . . . .Track Load Button (Shift: Open Folder [R], Close Folder [L])
T22.
. . . . .High (Highs EQ) Dial
T23.
. . . . .Mid (Mids EQ) Dial
T24.
. . . . .Low (Bass EQ) Dial
T25.
. . . . .Cue Button (Shift: Track Pre-Listen Play [L] / Stop [R])
T26.
. . . . .Linefader
T27.
. . . . .Master Volume Dial (analog, not software)
T28.
. . . .Phones Volume Dial (analog, not software)
T29.
. . . . .Cue Mix Fader
T30.
. . . . .Power Status LED (illuminated when controller is turned on, if voltage is provided)
T31.
. . . . .MIDI Status LED (illuminated when transferring MIDI signal)
T32.
. . . . .Master Level LED Indicator
T33.
. . . . .Crossfader
Rear Panel
B39.
. . . . .Mains Cord Strain Relief
B40.
. . . .Mains Adapter Connection (DC6V/1.5A)
B41.
. . . . .On/Off Button
B42.
. . . .USB Port
B43.
. . . .MIDI Channel 1/2 Switch
B44.
. . . .Shift Lock On/Off Switch
B45.
. . . .Jog Sensitivity Dial
B46.
. . . .LED Dimmer Dial
B47.
. . . . .RCA Output (Audio Outputs)
Front Panel
F34.
. . . . .6.3 mm Jack Microphone Connection
F35.
. . . . .Microphone Level Dial
F36.
. . . . .SW/Thru/Off Switch (switches microphone routing)
F37.
. . . . .6.3 mm Jack Headphones Connection
Right Side
S38.
. . . .Kensington Lock
