REMdevice BRICK 09K - TECHNICAL FEATURES; Common Transmitter and Receiver Parameters; Receiver Unit Specifications; Transmitter Unit Specifications

Installation, start up and operating manual – version 5.3 Gen.10
Radio control BRICK and PAIL
TECHNICAL FEATURES
Parameters common to the transmitter and receiver units
Operating frequency:
869,700– 870,000 MHz/ Channels width 25kHz/ N.° channels 11
433,050– 434,790 MHz/ Channels width 25kHz/ N.° channels 59
Hamming distance code: 4
Maximum no. Contemporary on/off command activation: 10
Commands response time: 45 ms
Active emergency stop command response time: 45 ms
Passive emergency command response time: 1 s
Range of action: 100 m
Working/storage temperature: -20°C / +70°C
Receiver unit
Radio frequency receiver unit: Single Chip
Antenna: ¼ λ amplified
Commands relay contacts capacity: 4A 115 Vac.
Stop relay contacts capacity: 4A 115 Vac.
Power supply (depending on model): DC 10-30V 1,0A,
AC/DC 24-48V or AC/DC 48-115V 50-60 Hz 0,4A
Container: Modulbox for fixing on bracket DIN EN 50022
Modulbox’s degree of protection: IP20
Modulbox’s dimensions: 158×90×75 mm (L×H×D)
Sealed casing for external fixing: ABS, Prot, deg. IP55
Dimensions: 266×169×89 mm (L×H×D)
Transmitter unit
Modulation: FM Manchester
Radio frequency output power: 5 mW
Oscillator: digital synthesising PLL
Antenna: ¼ λ integrated
Power supply: 3.6 Vcc.
Electricity Consumption : 45 mA
Accumulators: integrated 3×1,2V 1800mA
Length of autonomy time: ≈ 35 hours ( 20°C )
Autonomy after batteries low warning: 60 minutes
Casing’s degree of protection: IP 55, material ABS
Dimensions: BRICK 210×95×40 – PAIL 200x135x130 mm (L×H×P)
Weight: BRICK 470 g. - PAIL 500 g.
