Setting accuracy Temperature: 0.5°C.
Clock program: 10 minutes
Wireless range (iSense RF)
The range of the iSense RF in buildings is generally 30 metres.
The range is influenced strongly by the prevailing situation. (see paragraph 3.1)
Operation Menu-controlled using push buttons and a push-turn button
Installation Directly on the wall using screws or built-in junction box as per standards.
Built-in system possible using built-in part (art. S100994)
Quality marks and
compliance with standards
EMC: 89/336/EEC – EN50165(1997), 55014, 55022
Emission EN61000-6-3
Immunity EN61000-6-2
Drop test: IEC 68-2-32
RoHS compliant
OpenTherm V3.0 (iSense OpenTherm only)
ETSI 220-300 (iSense RF only)
Protection class IP20 for wall installation, IPx4 for the built-in system.
