Spare parts list
When ordering spare parts, please state the EDP no., unit number and type (see name plate)!
xx = not illustrated
No. Designation CLK 30 CLK 50 CLK 70 CLK 120 CLK 150
EDP no. EDP no. EDP no. EDP no. EDP no.
1 Cover panel 1104703 1104703 1104740 1104770 1104770
2 Insulation, top 1104704 1104704 1104741 1104771 1104771
3 Insulation, right 1104705 1104705 1104742 1104772 1104772
4 Side panel, top right 1104706 1104706 1104743 1104773 1104773
5 Side panel, bottom right
1104707 1104707
1104744 1104774 1104774
6 Floor pan 1104708 1104708 1104745 1104775 1104775
7 Insulation, bottom 1104709 1104709 1104746 1104776 1104776
8 Side panel, top left 1104710 1104710 1104747 1104777 1104777
9 Side panel, bottom left 1104711 1104711 1104748 1104778 1104778
10 Insulation, left 1104712 1104712 1104749 1104779 1104779
11 Back panel, compl. 1104713 1104737 1104750 1104780 1104805
15 Insulation 1104714 1104714 1104751 1104781 1104781
17 Switching cabinet, compl. 1104716 1104753 1104783 1104807 1104808
18 Seal for switching cabinet 1104717 1104717 1104754 1104754 1104754
19 Front wall 1104718 1104718 1104755 1104785 1104785
20 Front wall insulation 1104719 1104719 1104756 1104786 1104786
22 2-line oil filter 1002526 1002526 1002526 1002526 1002526
25 Guide bracket 1104720
1104720 1104757 1104787 1104787
26 Holding bracket, oil filter 1104721 1104721 1104721 1104721 1104721
27 Multiflex oil pre-heating, compl. 1071410 1071410 1071410 1071410 1071410
28 O-ring 1108464 1108464 1108464 1108464 1108464
29 Filter insert 1108462 1108462 1108462 1108462 1108462
30 Oil filter cup 1108463 1108463 1108463 1108463 1108463
31 Hose pass-through 1104722 1104722 1104722 1104722 1104722
32 Outlet nozzle 1104723 1104723 1104758 1104788 1104788
33 Burner housing 1104724 1104724 1104759 1104789 1104789
35 Support foot 1104725 1104725 1104725 1104790 1104790
36 Axle 1104726 1104726 1104760 1104791 1104791
37 Wheel 1101621 1101621 1101621 1108369 1108369
38 Hubcap 1101623 1101623 1101623 1101623 1101623
39 Locking ring 1101622 1101622 1101622 1101622 1101622
45 Combustion chamber, compl. 1104727 1104738 1104761 1104792 1104806
46 Sealing cap ———— ———— 1104728 1104784 1104784
47 Exhaust gas suppressor (set) 1104729 1104762 1104793 1104809 1104810
48 Inspection cover 1104730 1104730 1104763 1104794 1104794
49 Seal for inspection cover 1104731 1104731 1104764 1104795 1104795
50 Collar, exhaust gas nozzle 1104732 1104732
1104732 1104796 1104796
55 Transportation bracket, front 1104733 1104733 1104765 1104797 1104797
56 Transportation bracket, rear 1104734 1104734 1104766 1104798 1104798
57 Transportation bracket, middle 1104735 1104735 1104767 1104799 1104799
58 Crane eye 1102554 1102554 1102554 1102554 1102554
60 Fan, compl. 1108158 1108199 1108178 1104815 1104815
61 Condenser (fan) 1102516 1102716 1102817 1104802 1104802
63 Safety temperature limiter (STB) 1101197 1101197 1101197 1101197 1101197
64 Temperature controller (TR) 1103166 1103166 1103166 1103166 1103166
65 Temperature monitor (TW) 1103146 1103146 1103146 1103146 1103146
66 Operating switch 1101188 1101188 1101188 1101188 1101188
67 Indicator light, green (Operation) 1105514 1105514 1105514 1105514 1105514
68 Indicator light, red (Burner fault) 1105363 1105363 1105363 1105363 1105363
69 Reset button (Burner) 1103408 1103408 1103408 1103408 1103408
70 Thermostat socket 1101018 1101018 1101018 1101018 1101018
71 Strapping plug 1101019 1101019 1101019 1101019 1101019
72 Mains cable with plug 1104701 1104701 1104701 1104701 1104701
xx Burner connector, 7-pin 1102537 1102537 1102537 1102537 1102537
xx Drum fitting, compl. 1002544 1002544 1002544 1002544 1002544
xx Cleaning brush, compl. 1103110 1103110 1103110
1103110 1103110
