23
Technical data
We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
Unit type CLK 30 CLK 50 CLK 70 CLK 120 CLK 150
Nominal heat load max
. kW 29 46 68 114 150
Nominal heat capacity P
nom
kW 26.5 42 62 105 138
Minimum heat capacity P
min
kW N.A. N.A. N.A. N.A. N.A.
Room heating emissions
mg/kWh
121 122 N.A. N.A. N.A.
Nominal flow rate
1)
m
3
/h 1,760 3,050 4,920 8,050 9,710
Temperature increase Δ
t
K 45 52 46 50 51
(Max. total) pressure Pa 90 145 165 220 260
Fuel Heating oil EL acc. to
DIN 51603 or diesel fuel
Fuel Liquid gas cat. I
3B/P
Max. fuel consumption (heating oil) l/h 2.85 4.5 6.6 11.2 14.8
Max. fuel consumption (liquid gas) kg/h 2.3 3.6 5.3 8.9 11.7
Danfoss oil nozzle
2)
USG
0.6/60°S 1.00/60°S 1.35/60°S 2.25/80°S 2.75/80°S
Pump pressure, approx.
2)
bar 11.0 11.0 12.0 12.0 14.0
Liquid gas connection pressure mbar 50 50 50 50 50
Auxiliary power consumption
at nominal heating capacity el
max
kW 0.370 0.420 0.860 1.800 1.900
at minimum heating capacity el
min
kW 0.000 0.000 0.000 0.000 0.000
in Stand-By mode el
SB
kW 0.000 0.000 0.000 0.000 0.000
Pilot flame power requirement P
pilot
kW N.A. N.A. N.A. N.A. N.A.
Thermal efficiency at nominal
heating capacity
η
th,nom
% 92.8 92.2 92.9 91.3 91.4
Thermal efficiency at minimum
heating capacity
η
th,min
% N.A. N.A. N.A. N.A. N.A.
Type of room temperature control
Room temperature control with mechanical
thermostat
Exhaust gas flow,
approx. kg/h 48 75 115 180 235
Combustion chamber resistance (start up / operation)
Pa 145/40 150/45 180/80 400/90 480/120
Required flue draft Pa 0 0 0 0 0
Power supply V/Hz 230/1~/50
Max. nominal current
(complete unit) A 1.8 2.0 4.0 8.2 8.8
Operating condenser
(fan) μF 3 5 14 30 30
Max. power consumption
(oil preheating) W — — — 30 30
Electrical protection (provided by the customer)
A 10 10 10 16 16
Sound pressure level L
pA
1m
3)
dB (A) 54 61 61 72 72
1) At Δ
t
45K/1.2 kg/m
3
)
2) The specified nozzle sizes and pump pressures are based on test bench results.
The oil flow rate was derived from this.
Based on the product-specific nozzle and pressure tolerances as well as the oil temperature, the specifications should only be
considered guidelines.
3) Workplace-related emission value 1m LpA as per DIN ISO 11203 (without burner mode)
