Parameter list (expert level) - continued
No. Description Code
Para-
meter
Value Range
31 Used storage tank probe solar
n
n01 0 0-bottom/1-top
32 Min. run-time solar pump n02 15 min 1-30 min
33 Start temperature difference solar n03 5° C 0~20 °C
34 Night reduction n04 0/no 0-no/1-yes
35 Start time night reduction n05 00 h 00~23 h
36 End time night reduction n06 6 h 00~23 h
37 Start temperature night reduction n07 70 °C 40~90 °C
38 End temperature night reduction n08 10 °C 1~40 °C
39
Max. storage tank temperature for the solar change-
over valve
n09 68 °C 50~90 °C
40 Max. storage tank temperature solar pump stop n10 70 °C 50~90 °C
41
Solar pump operation storage tank temperature-
independent
n11 0/no 0-no/1-yes
42 Start collector temperature solar pump
r
r01 55 °C 10~60 °C
43 PV function r02 0/1 1
44 Hysteresis setpoint HW water r03 5 °C 1~20 °C
45 Parallel operation heat pump/heating coil r04 0/no 0-no/1-yes
46 Switch-on temperature elec. Heating coil r05 55 °C 30~90 °C
47 Switch-on delay elec. Heating coil r06 200 min 0~450 min
48
Elec. heating coil replaces compressor
1)
r07 0 0-no/1-yes
49 Lower heat pump usable limit r08 -5 °C -20~10 °C
50 Bivalence point elec. heating coil without delay r09 10 °C 0~30 °C
51 Bivalence point elec. heating coil with time delay r06 r10 25 °C 10~40 °C
52 Circulation pump runtime r11 60 s 0~255 s
53 Lower heat pump emergency stop usable limit r12 -15 °C -5~-30 °C
54 No function r13 56 °C 50~56 °C
55 Setpoint with PV yield r14 45 °C 10-60 °C
56 High temperature condenser stop temperature r15 -30 °C Factory setting
57 Minimum temperature for fan speed control r16 -30 °C Factory setting
58 Top tank probe active/inactive r17 0 Factory setting
59 Return flow temperature increase (heating) r18 0 °C Factory setting
60 Factory setting r19 -30 °C Factory setting
61 Factory setting r20 -30 °C Factory setting
49
