Parameter list (operator level)
No. Description
Para-
meter
Value Range
1 Start defrost temperature (evaporator) d01 -3°C -30°C~0°C
2 End defrost temperature (evaporator) d02 13°C 2~30°C
3 Time between defrosts d03 45 min 30~90 min
4 Max. defrosting period d04 8 min 1~12 min
5 Duration of legionella function g02 0 min 0~90 min
6 Time start of legionella function g03 0 h 0~23 h
7 Time interval (days) of legionella function g04 7D 7~99 days
8 Max. storage tank temperature solar pump stop n10 70°C 50~90°C
9 Switch-on delay electr. heating coil r06 200 min 0~450 min
Parameter description
Para-
meter
Designation Description
d01 Start defrost temperature (evaporator)
If the evaporator temperature is < d01 then the
defrosting process starts
d02 End defrost temperature (evaporator)
If the evaporator temperature is > d02 then the
defrosting process ends
d03 Time between defrosts
This is the min. run-time of the heat pump
between 2 defrosting processes
d04 Max. defrosting period Once the set time d04 lapses, defrosting ends
g02 Duration of legionella function Time of the legionella function
g03 Time start of legionella function The legionella function starts at this time
g04 Time interval (days) of legionella function
The legionella function is activated at this
interval (number of days)
n10 Max. storage tank temperature solar pump stop
If the storage tank temperature is higher than
n10, the solar pump r06 stops: Switch-on delay
electrical heating coil. Upon exceeding the set
run-time r06, the electrical heating coil is
switched on
51
