Heating capacity WLT 60 EC - WLT 90 EC
VS LV SD
Medium
nominal
Medium inlet
35 °C 40 °C 45 °C 50 °C 55 °C 60 °C 65 °C
Heating capacity
Mediu
m flow
rate
[m
3
/h]
Pres-
sure
loss
[kPa]
Q
H
[kW]
Q
H
[kW]
Q
H
[kW]
Q
H
[kW]
Q
H
[kW]
Q
H
[kW]
Q
H
[kW]
WLT 60
EC
1 150 18 0.250 19.0 0.64 0.85 1.06 1.25 1.45 1.64 1.83
2 705 35 0.676 19.0 2.52 3.35 4.19 4.95 5.75 6.50 7.23
3 895 41 0.804 25.2 3.09 4.11 5.14 6.07 7.06 7.97 8.87
4 1050 46 0.924 31.0 3.37 4.49 5.61 6.63 7.71 8.71 9.69
5 1120 47 1.047 38.4 3.97 5.29 6.61 7.81 9.08 10.3 11.4
WLT 80
EC
1 320 19 0.490 14.3 1.19 1.60 1.98 2.27 2.73 3.09 3.44
2 1090 40 0.832 14.3 3.11 4.19 5.19 5.94 7.15 8.08 9.00
3 1300 44 1.041 19.0 3.90 5.24 6.49 7.43 8.94 10.1 11.3
4 1490 47 1.179 23.7 4.44 5.98 7.40 8.47 10.2 11.5 12.8
5 1650 50 1.278 27.4 4.95 6.66 8.25 9.44 11.4 12.8 14.3
WLT 90
EC
1 320 20 0.370 13.9 1.34 1.77 2.18 2.36 2.97 3.34 3.68
2 1300 44 1.023 13.9 4.81 6.38 7.84 8.5 10.7 12.0 13.3
3 1460 46 1.353 22.9 5.38 7.14 8.78 9.51 12.0 13.5 14.8
4 1640 49 1.491 26.9 5.94 7.88 9.69 10.5 13.2 14.9 16.4
5 1790 51 1.599 30.0 6.38 8.46 10.4 11.3 14.2 16.0 17.6
Air inlet temperature TK 20 °C, 0% Glycol concentration, max. air flow
Q
H
= Heating capacity
, total
LV = Air flow [m
3
/h]
SD = Sound pressure level [dB(A)]
VS = Fan stage
