Renault J8S - Crankshaft Data; Direction for Fitting the Circlips on the Piston

ENGINE AND PERIPHERALS
Specifications
10
10-28
Direction for fitting the circlips on the piston
Fit the circlips on the piston as shown below.
CRANKSHAFT
Number of bearings 5
Burnishing
●
normally aspirated engine with
●
turbo engine 1
st
fitting without
●
turbo engine 2
nd
fitting with
N.B.: non-burnished crankshafts fitted on turbo
engines can be redressed using the values given in
the table.
98365S
in mm
Longitudinal play
●
normally aspirated engine
1
st
model: 1 to 32 909
●
normally aspirated engine
2
nd
model: from 32 910
●
turbo engine
1
st
and 2
nd
models
0.07 to 0.25
0.20 to 0.30
0.20 to 0.30
Bushing
Nominal diameter
Repair diameter
62.88
62.63
- 0
- 0.019
- 0
- 0.019
Crankpin
Nominal diameter
Repair diameter
56.296
56.046
- 0.010
- 0.029
- 0.010
- 0.029
