ENGINE AND PERIPHERALS
Overhauling the engine
10
10-83
Use a cloth to wipe up any excess paste, both inside
and outside the cylinder block, and at (A).
Pass a thin wire through the lubricating channels to
check that they have not been blocked (this can also
be done using a compressed air gun).
Allow to dry for a few moments and cut the excess off
the gasket face.
89197R
89198S
89199S
