3.02
AIR VENTS (air outlets)
1 - left-hand air vent
2 - left-hand window demister outlet
3 - windscreen demister outlets
4 -centreairvents
5 - control panel
6 - right-hand side window demister
outlet
7 - right-hand side air vent
8 - footwell heater outlets for front
passengers
