1.80
FUEL TANK
Capacity of fuel tank:
80 litres approximately.
To open flap A,pressonthearea
shown by the arrow.
The flap opens a little. Twist it to
open fully.
The filler cap is incorporated in the
filler neck.
Refer to the information on Filling
up with fuel for more details.
Special notes for hands-free
RENAULT Cards
The flap locks a few minutes after
the other doors on the vehicle.
Never press the metal
valve with your fingers.
Do not wash the filling
area with a high pressure jet
spray with the filler flap open or
in icy conditions as the valve
may become iced up.
Special circumstances
If the RENAULT Card is faulty, it is
possible to unlock flap A by
manually operating the unlocking
rod (inside the boot).
To access the flap, lift the grille
giving access to the rear light bulbs,
compartment side, and pull the
locking button towards you 1.
