3.04
AUTOMATIC AIR CONDITIONING
The controls
1 - automatic mode operation
button
2 - left-hand temperature adjust-
ment button
3 -display
4 - right-hand temperature adjust-
ment button
5 - air recirculation and automatic
recirculation function button
6 - system off button
7 - air distribution adjustment
button
8 - ventilation speed adjustment
button
9 - “clear view” button to demist
and de-ice the windows
10 - rear screen de-icing button
11 - air conditioning button
Information and operating
instructions: refer to the end of the
section on Heating / air
conditioning.
Buttons 1, 5, 6, 9, 10 and 11 have
integral operating indicator
lights:
- indicator light lit up, the
function is switched on,
- indicator light off, the function
is switched off.
