5.03
TOOL KIT
The tool kit A is located in the boot,
on the spare wheel.
Jack 1
Unclip the jack retaining tab.
Remove jack 1.
When replacing the jack, fold it up
completely and replace it in its
location.
The jack is designed for
wheel changing only. It
should never be used for
repairs or gaining access
to the underside of the vehicle
Wheel brace 2
This is used to tighten or release the
wheel bolts.
Hubcap spanner 3
This spanner is used to remove
hubcaps.
Towing ring 4
Refer to the information on
“towing” in Section 5.
Storage compartments
Storage compartments are provided
in the tool kit for a fuse box, an
immobiliser bolt and an
immobiliser spanner.
