5.21
FUSES
Fuse box 1
If a fault occurs in an electrical
component, check first of all that
the fuses are sound.
Open cover 4.
To identify the fuses, refer to label 3
(shown on the page opposite).
It is not advisable to use the free
fuse locations.
Check the fuse in question
and, if necessary, replace it
with a fuse of the same
rating.
If you fit an over-rated fuse, it may
cause the electrical circuit to
overheat (risk of fire) in the event of
a consumer drawing an excessive
current.
CORRECT INCORRECT
Use tweezers to remove the fuse 2.
Toremovethefusefromthe
tweezers, slide the fuse to the side.
Note:
Close cover 4 again before closing
the vehicle door.
In accordance with local
legislation or as a precautionary
measure:
Obtain a box of spare bulbs and
fuses from your RENAULT
Dealer.
