1.18
FRONT HEADRESTS
To adjust the height
While sitting on the seat, pull the
headrest towards you and slide it up
or down at the same time.
To remove the headrest
With the headrest at mid-height, lift
tab 1, then lift the headrest to
remove it.
To adjust the angle of the headrest
The angle of the headrest can be
adjusted. To do this, move the front
section A of the headrest forwards
or backwards until it feels
comfortable.
To refit the headrest
Insert the rods into the sleeves, with
the notches facing the front.
Lower the headrest until it locks in
position.
The headrest is important
for safety. Ensure that it is
in place and in the correct
position. The distance
between your head and the
headrest should be as small as
possible. The top of your head
should be in line with the top of the
headrest.
