AUTOMATIC AIR CONDITIONING (continued)
Rear passenger controls
Adjusting the amount of air
blown into the passenger
compartment
Move control A from OFF to MAX.
Passenger compartment ventilation
is referred to as “blown air”.
The ventilation fan determines the
air flow.
The air vent is closed in the OFF
position.
The further the control is positioned
to the right, the greater the quantity
of air blown into the passenger
compartment.
Distribution of air in the
passenger compartment
Move control B.
• Position
The air flow is directed mainly
towards the air vents 1.
• Position
The air flow is directed towards the
air vents 1 and the footwells.
• Position
The air flow is directed mainly
towards the footwells.
