CHILD SAFETY (continued)
Isofix seat additional mounting
rings
Each of the rear side seats is fitted
with two rings for mounting the
base of the child seat.
Consult your RENAULT Dealer for
how to access the rings the first time
you install the seat.
For the mounting ring on a
front-facing seat, use belt 4 supplied
with the seat:
-passbelt4 between the two rear
headrest rods;
- attach hook 5 to ring 6 located
inside the boot.
For the mounting ring on a
rear-facing seat, use belt 4 supplied
with the seat:
- slide the cover to access ring 7;
-attachbelthook5 to ring 7.
