Page #27 background image
Renesas RA Family RA4 Quick Design Guide
R01AN5988EU0100 Rev.1.00 Page 27 of 51
Jul.21.21
Table 13. Pin Assignments for Emulator
Pin No.
SWD
JTAG
Serial Programming
Using SCI
1
VCC
VCC
VCC
2
P108/SWDIO
P108/SWDIO
NC
4
P300/SWCLK
Wired OR with P201/MD
P300/TCK
Wired OR with P201/MD
P201/MD
6
P109/SWO/TXD9
P109/TDO/TXD9
P109/TDO/TXD9
8
P110/SWO/RXD9
P110/TDI/RXD9
P110/TDI/RXD9
9
GNDdetect
GNDdetect
GNDdetect
10
nRESET
nRESET
nRESET
12
P214/TCLK
P214/TCLK
NC
14
P211/TDATA[0]
P211/TDATA[0]
NC
16
P210/TDATA[1]
P210/TDATA[1]
NC
18
P209/TDATA[2]
P209/TDATA[2]
NC
20
P208/TDATA[3]
P208/TDATA[3]
NC
3,5,15,17,19
GND
GND
GND
7
NC
NC
NC
11,13
NC
NC
NC
