Renesas RH850/D1x Hardware Specification

D1M1A Mango Adapter Board Manual
【DRAFT VERSION - CONFIDENTIAL】
12
5 External Memory function
5.1 Serial Flash
The serial flash can be used by setting DSW1.1=ON and by closing JP32 and opening JP33. It cannot be used
simulaneuously with NAND Flash.
Type
Size
Interface / Speed
Package
1x MX66L1G85G (Macronix)
1Gbit (128MB)
8bit, DDR@80MHz
TFBGA-24
5.2 NAND Flash
The NAND flash can be used by setting DSW1.1=ON and by opening JP32 and closing JP33. It cannot be
used simulaneuously with Serial Flash.
Type
Size
Package
1x MT29F4G08ABADAWP-IT (Micron)
4Gbit (512MB)
TSOP-48
5.3 Octa MCP
Port P21 is equipped with with OctaBus type memory. To use both RAM and Flash of the device, please close
jumpers JP34, JP36 and JP37.
Type
Size
Package
1x MX65L12A64AA (Macronix)
512Mbit (64MB)
TFBGA-24
5.4 SDR-SDRAM
Type
Size
Interface / Speed
Package
2x MT48LC16M16A2P-6A (Micron)
2 x 256Mbit (32MB)
32bit, SDR@120MHz
TSOP-54
5.5 Mounted devices
Table 5-1: Mounted devices
Loc.
Manufacturer
Product name
Note
U2
Macronix
MX66L1G85G
1Gbit: DDR@80MHz,
Dual Quad Serial Flash Memory
JP32 closed and JP33 opened
U3
Micron
MT29F4G08ABADAWP-IT
4Gbit
NAND Flash Memory
JP32 opened and JP33 closed (default)
U5
Macronix
MX65L12A64AA
512Mbit Flash and 64Mbit RAM
Octa MCP Memory
JP34, JP36 and JP37 closed
UM3
UM4
Micron
MT48LC16M16A2P-6A
256Mbit x 2: SDR@120MHz,
SDR-SDRAM Memory
