D1M1A Mango Adapter Board Manual
【DRAFT VERSION - CONFIDENTIAL】
18
7 Socket
This chapter lists all connectors of the D1M1A adapter board. There are mainly three groups of connectors.
7.1 Overview
Adapter boards of MCU block cosists of below components.
・ IC socket
・ Test pin area and external connectors
・ Main board connectors
D1x series have several package variant, therefore the IC socket depends upon the package variant.
7.2 RH850/D1M1A adapter board structure
Figure 7-1 shows D1M1A adapter board block diagram.
Figure 7-1: Block diagram of the MCU connections on the D1M1A Adapter board
7.3 Mounting socket
This board will be fitted with one of the socket types as shown below.
Table 7-1: IC socket (For the BGA272 Adaptor Board)
Can be plugged into the BGA to Pin
adapter. Device will be inserted into the
LSPACK
BGA to Pin adapter. To be soldered.
BSSOCKET connects to LSPACK
To Next Page
