Renesas RH850/D1x Hardware Specification

D1M1A Mango Adapter Board Manual
【DRAFT VERSION - CONFIDENTIAL】
15
6 Multiplex Control
6.1 Overview
Multiplexers (mainly for Memory, Video I/O and Ethernet) shall be manually controlled by the user themselves
via DIP switches (DSW1). Thus, the user has responsibility to avoid misconfiguration of the multiplexers that
might destroy the device.
The following multiplexers are placed onto the adapter board.
Table 6-1: Signal Assignment and function of DSW1
Switch Position
Signal name
ON Function
OFF Function
DSW1.1
MUX_CONTROL1
Connect to Memories
(Dual Quad and NAND
Flash)
*1
Connect to Main board
DSW1.2
MUX_CONTROL2
Conect to P42 or P43
*2
Connect ot Ether
*3
DSW1.3
-
-
-
DSW1.4
-
-
-
DSW1.5
-
-
-
DSW1.6
MUX_CONTROL6
Connect to Vout
Connect to LVDS
DSW1.7
MUX_CONTROL7
Connect to P42
*2
Connect to P43
*2
DSW1.8
MUX_CONTROL8
Connect to P3_0 and
P3_1
Connect to Ether
*3
*1: When using NAND Flash, JP33 is closed and JP32 is open (Default).
When using Dual Quad, JP33 is open and JP32 is closed.
*2: It is combination setting DSW1.2 and DSW1.7.
*3: It is combination setting DSW1.2 and DSW1.8.
