Renesas RH850/D1x Hardware Specification

D1M1A Mango Adapter Board Manual
【DRAFT VERSION - CONFIDENTIAL】
6
1 Introduction
The RH850/D1x Application Board is part of the RH850 Evaluation Platform and serves as a simple and easy to
use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/D1x
microcontrollers.
Since the adapter board cannot be used as a standalone board, this board has to be mated with a mainboard for
full functionality.
Main features of the adapter board:
 Socket for mounting a device
 Power supply from main board
 Device programming capability (Connector on main board)
 Device debugging capability (Connector on main board)
 Pin headers for direct access to each device pin
 MainOSC and SubOSC circuitry
 Connectors to MainBoard
 SDR-SDRAM, NAND Flash, Serial Flash and Octa MCP
This document describes the functionality provided by the adapter board and guides the user through its
operation.
For details regarding the operation of the microcontroller, refer to the RH850/D1x User Manual.
