Instruction Manual
1. Appliance Description
1.1 MT3
1 hose clamp
5 grinding table
6 door latch (4x)
7 mains plug
8 drain hose
9 water hose
11 pull-off tool
12 water connection
Symbols
Danger!
Immediate risk of injury.
High Voltage!
Danger – high voltage.
Caution:
Risk of damage to the unit if the instruction is not followed.
Notice
A general notice that improves and eases use.
Caution:
Wear protective glasses.
IPX2 The appliance is protected agains dripping water from 15° angle.
The appliance complies with applicable EU directives.
Within the EU, this device is subject to the provisions of the directive 2002/96/EG (WEEE directive).
13 darin water connecting branch
14 water inlet
15 cover
16 fastening screw
17 lock pins
18 rinse tube
21 bracket
22 Allen key, SW4
5
6
2
7
8
9
11
12
13
23
22
21
18
15/16/17
14
Fig. 1
