- 6 -
EN
4.4 Cleaning rinse tube
Turn off appliance and wait, until the trimmer disk comes to an complete standstill.
Close water supply shutoff tap.
Pull grinding table (5) at leading edge upward from ball head
.
Turn rinse tube (18) backwards at curved side and take out (Fig 11).
18
Fig. 11
Allow the rinse tube to soak in decalcifying agent overnight
Replace rinse tube by pressing rinse tube into both clamps (Fig. 12)
.
„klick“
Fig. 12
4.5 Cleaning water inlet sieve
Pull mains plug.
Close water supply shutoff tap.
Disconnect water hose (9, Fig. 3) from water connection (12, Fig 3).
Use pliers to pull out sieve and clean it.
Put sieve back in place.
Fig. 13
4.6 Flange Replacement
Turn off appliance and wait, until the trimmer disk comes to an complete standstill.
Pull mains plug.
Remove the disc (chap. 3.4).
Unscrew the pull-off tool.
If necessary, clean the hub.
>>> Note the engagement groove.
Reinstall the grinding disc (chap. 3.4).
Put door back in postion and close the door latches.
Plug in at the mains.
5. Spare Parts
Refer to the spares list at the end of this manual for numbers of wearing and replacement parts.
Serial number and date of manufacturing are shown on the type plate of the unit.
11
23
Fig. 14
Fig. 15
4.2 Cleaning internal space
Turn off appliance and wait, until the trimmer disk comes to an complete standstill.
Clean door with a brush or cleaning cloth under running water
Wipe the internal space with a brush or cleaning cloth.
4.3 Cleaning grinding table
Turn off appliance and wait, until the trimmer disk comes to an complete standstill.
Pull grinding table (5) at leading edge upward from ball head
.
Clean grinding table with a brush under running water.
EN
