Autojoint to autojoint
These extension bars are compatible with the PH10M PLUS and PH10MQ PLUS heads. They allow direct connection to the head via the
autojoint and terminate in an autojoint. This permits use of a multiwired probe.
Extensions Length Material Weight
PEM25 25 mm Aluminium 60 g
PEM1 50 mm Aluminium 64 g
PEM2 100 mm Aluminium 93 g
PEM3 200 mm Aluminium 147 g
M8 thread to M8 bush
These extension bars can be used directly with the PH10T PLUS head, and also with the PH10M PLUS and PH10MQ PLUS heads using the
PAA1 adaptor.
Extensions Length Material Weight
PEL1 50 mm Aluminium 22 g
PEL2 100 mm Aluminium 43 g
PEL3 200 mm Aluminium 80 g
PEL4 300 mm Aluminium 141 g
