4-4
Primo™ system: Dimensions and specications
Part setter specication
Principal application Used for workpiece set-up and inspection.
Dimensions Length 61.25 mm (2.41 in)
Diameter 51 mm (2.01 in)
Weight without shank (includ-
ing battery and credit token)
350 g (12.35 oz)
Transmission type Frequency-hopping spread spectrum (FHSS) radio.
Radio frequency 2400 MHz to 2483.5 MHz
Operating range Up to 10 m (32.8 ft)
Receiver/interface Primo™ interface
Recommended stylus M4 stylus with 50 mm (1.97 in) ceramic stem and 6 mm (0.24 in) ruby ball.
Switch-on / switch-off options Radio on Radio off Spin on Spin off
Spindle speed (maximum) 1000 r/min
Sense directions ±X, ±Y, +Z
Unidirectional repeatability 1.00 µm (40 µin) 2s
1
Stylus trigger force
2
3
Factory setting:
XY low force
XY high force
+Z
0.50 N, 51 gf (1.80 ozf)
0.90 N, 92 gf (3.24 ozf)
5.85 N, 597 gf (21.04 ozf)
Mounting Taper shank in machine tool spindle.
Environment IP rating IPX8, BS EN 60529:1992+A2:2013
Storage temperature −25 °C to +70 °C (−13 °F to +158 °F)
Operating temperature +5 °C to +55 °C (+41 °F to +131 °F)
Battery types 1 × ½ AA (3.6 V) lithium‑thionyl chloride 1 × CR2 (3 V) lithium‑manganese dioxide
Battery life See table below.
Low battery indication Flashing blue LED while the part setter is seated (not triggered).
Dead battery indication Continuous red LED.
Low credit indication Flashing yellow LED while the part setter is seated (not triggered).
No credit indication Continuous yellow LED.
1 Performance specification is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 50 mm (1.97 in) stylus
Significantly higher velocity is possible depending on application requirements.
2 Trigger force, which is critical in some applications, is the force exerted on the component by the stylus when the probe
triggers. The maximum force applied will occur after the trigger point (for example overtravel). The force value depends on
related variables including measuring speed, machine deceleration and latency.
3 These are the factory settings; manual adjustment is not possible.
Typical battery life
Battery type Standby life 5% usage (72 minutes/day) Continuous use
CR2 lithium manganese dioxide 270 days 75 days 155 hours
½ AA lithium-thionyl chloride 410 days 125 days 260 hours
