Renishaw RMI-Q Installation Guide

3.1
Mounting bracket (optional)
System installation
Dimensions given in mm (in)
25
(0.98)
25
(0.98)
19 (0.75)
38 (1.50)
3 grip protrusions
100.5 (3.95)
2.0 (0.08)
30
(1.18)
25
(0.98)
45
(1.77)
45 (1.77)
45°
90 (3.54)
3 pairs of holes
Ø5.5 (0.20)
permit RMI-Q
mounting in
alternative
orientation
2.0
(0.08)
3 holes Ø6.4 (0.25)
NOTES:
Install RMI-Q with cable exiting from lower side for
good coolant run off.
Mounting bracket cannot be used with an RMI-Q
in rear exit configuration.
