Fitting a probe module and stylus onto a probe body
1. Visually examine the mating faces of both the probe module and the probe head for cleanliness. Where necessary, clean the mating
surfaces using the CK200 cleaning kit (supplied).
2. Offer up the probe module to the probe body and, ensuring the three alignment marks on both the probe module and probe body are
correctly aligned, allow the probe module to engage the probe body under magnetic force.
