6-way probe module
The recommended stylus limits for the 6-way probe module are:
Any stylus type up to 30 mm long
Star and cranked styli up to 10 mm offset
Comparative stylus lengths
A comparison of the minimum and maximum stylus lengths for use with each probe module is shown in the following figure:
