11
2.Unscrew PV terminals by rotating counterclockwise to open the hatch. Then connect
the positive and negative battery connections in their appropriate labeled terminal.
EN
3. Insert temperature sensor block terminal and connect wire. It is not polarity sensitive.
(Optional, requires a separate purchase).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Renogy Adventurer and is the answer not in the manual?

Renogy Adventurer Specifications

General IconGeneral
Rated Charge Current30A
System Voltage12V/24V Auto
Max PV Input Voltage50V
Max Output Current30A
SealingIP20
DisplayLCD
TypePWM Solar Charge Controller
Self-Consumption<10mA
Operating Temperature-35°C to +45°C
Max Input Power400W (12V), 800W (24V)
Battery TypeSealed, Gel, Flooded, and Lithium
ProtectionsOverload, Short-circuit
CommunicationRS232
