14
The user can select between displaying battery temperature in Celsius or Fahrenheit.
3.Battery TemperatureInterface Change from C° to F°
C
0
BATT.
F
0
BATT.
The Adventurer PWM charge controller has a reactivation feature to awaken a sleeping
lithium battery. The protection circuit of Li-ion battery will typically turn the battery off and
make it unusable if over-discharged. This can happen when storing a Li-ion pack in a
discharged state for any length of time as self-discharge would gradually deplete the
remaining charge. Without the wake-up feature to reactivate and recharge batteries,
these batteries would become unserviceable and the packs would be discarded. The
Adventurer will apply a small charge current to activate the protection circuit and if a
correct cell voltage can be reached, it starts a normal charge.
When using the Adventurer to charge a 24V lithium battery bank, set the system voltage
to 24V instead of auto recognition. Otherwise, the over-discharged 24V lithium battery
wouldn’t be activated.
NOTE
When using the Adventurer to charge lithium battery, the user is able to set Battery
Parameters. In the Battery Interface, select Lithium as Battery Type. Short press
“ENTER” to enter Battery Voltage selection interface.
Press “SELECT” to select the Battery Voltage. Press “ENTER” to confirm selection
and go to Charging Parameters Interface.
Press “SELECT” to change the Boost Voltage. The default setting is 14.2V and the
user is able to set it in the range 12.6~16.0V, with a step of 0.2V. Hold “ENTER” to
confirm the selection. The setting will also be automatically saved after 15 seconds
without holding “ENTER”.
4. Set Battery Type to Lithium Set Lithium Battery Parameters
The above settings are only available under Lithium Battery type.
CAUTION
V
12V
BATT.
V
12V
CHG
BATT.
Lithium Battery Activation
EN
