System Status Icons
Change the Parameters
Behavior
Constant: System is normal, but it is not charging.
Charging:
Constant:
The battery is at full charge.
Flashing: The battery is overvoltage.
Flashing:
The battery is under voltage.
The bars will be sequencing indicating the system is charging.
Icon
Simply hold the “ENTER” button for approximately 5 seconds until the display flashes.
Once flashing, then press “SELECT” until the desired parameter is reached and press
“ENTER” one more time to lock in the parameter.
In this interface, the user is able to select which type of battery is connected to the
charge controller. Choose from Sealed, Gel, or Flooded batteries.
The screen must be at the appropriate interface in order to change the specific parameter.
NOTE
The user is able to reset the current power generation (kWh) back to 0 kWh.
2.Battery Interface Set Battery Type
1.Power Generation Interface Reset
BATT.
TYPE
BATT.
TYPE
BATT.
TYPE
BATT.
TYPE
kWh
PV PV
AkWh
EN
The Adventurer is an easy to use controller requiring minimal maintenance. The user is
able to adjust some parameters based on the display screen. The user can manually
cycle through the display screens by using the “SELECT” and “ENTER” buttons
SELECT
Cycles forwards through the different display screens.
ENTER
Cycles backwards through the different select screens
&
Customize some parameters on the charge controller
Constant: System is abnormal.
Flashing: The bars are sequencing,indicating the controller
is activating over-discharged lithium battery.
