Renogy ONE M1 - Page 14

14
Communication Diagram
RV-C Communication
1. For REGO devices connected with RV-C daisy chain topology:
RV-C Daisy Chain Topology
Renogy ONE
Device 2
Device 1
Device N
RV-C
Communication
Cable
RV-C
Communication
Cable
RV-C
Communication
Cable
2. For REGO devices connected with RV-C backbone topology:
For backbone topology, please contact our customer service through renogy.com/contact-us/.
RV-C Backbone Topology
Renogy ONE
RV-C
Communication
Cable
RV-C
Communication
Cable
RV-C
Communication
Cable
RV-C
Communication
Cable
Device 2Device 1 Device N
...
Drop Tap
Renogy ONE Communication Architecture Energy Device Communication Connections
