Technical Specifications
Technical Specifications
Item Parameter
Product Name Renogy ONE M1
Model RMS-LP4-G2-US
Power Supply 8V to 16V DC (5V DC for USB Type-C)
Power Consumption < 2.5W (standby)
Ports
USB Type-C (5V DC)
RJ45 (CAN & RS485)
2-pin 3.81 mm pluggable terminal block (12V DC)
Wireless Communication
Wi-Fi (IEEE 802.11b/g/n 2.4GHz)
Bluetooth 2.1/4.2 and Bluetooth LE
Zigbee (IEEE 802.15.4)
Protocols RV-C / Modbus / Zigbee 3.0
Touch Screen
4 inches (480 x 480p)
White backlight with adjustable brightness
Load ≤30V DC, 5A Max / Channel
Operating Temperature 20 ℃ to 50 ℃ / 68 ℉ to 122 ℉
Operating Humidity 0% to 95% RH
Operating Altitude Less than 2000m above sea level
Installation Flush mounting
Dimensions 181.8 x 86.8 x 42.2 mm (7.16 x 3.42 x 1.66 in)
