20
Embedding
RS485 Communication
Recommended Accessories
Communication Cable (RJ45 Ethernet Cable)
Renogy Communication Hub
(For Multiple Devices)
HUB
NOT
E
z
Please use CAT5 and higher category cables.
z
Ensure that the device supports RS485 communication.
z
Please select the appropriate communication cable (sold separately) according to the
distance between devices. The length of the communication cable should be less than 30
meters (98.4 feet).
INF
O
z
Please read the user manual carefully before using Renogy Communication Hub.
z
When Renogy BT-2 Bluetooth Module is connected to the main communication port of
Renogy Communication Hub, the devices connected to Renogy Communication Hub will
have Bluetooth capability. You can add devices to Renogy ONE via Bluetooth. For details,
please refer to the Renogy Communication Hub User Manual.
1. Measure whether the communication cable
can be connected to Renogy ONE and
other devices.
12V Power Cable Communication Cables External Load
