Renogy WANDERER User Manual

04
General Information
4-Stage PWM Charging: Bulk, Boost, Float, and Equalization
The Wanderer is an advanced charge controller for off-grid
solar applications. Integrating highly efficient PWM charging,
this controller increases battery life and improves system
performance. It can be used for 12V/24V battery banks. The
controller is embedded with self-diagnostics and electronic
protection functions that prevent damages from installation
mistakes or system faults.
Automatic Voltage Detection for 12V/24V Non-Lithium
Systems and Lithium Battery Activation
Back-lit LCD for displaying system operation, diverse load
control, and error codes if any
Preset for Deep Cycle Sealed, Gel, Flooded Batteries and
Lithium-iron Phosphate Batteries
Integrated 5V, up to 2.1Amp USB for mobile or portable
device charging
Protection Against: overcharging, over-current, short circuit,
reverse polarity
Bluetooth Monitoring Ready port with addition of BT-1
Module and Renogy DC Home App
Key Features

Renogy WANDERER Specifications

General

Model	WANDERER
Max Input Power	130W (12V system, 10A) / 260W (12V system, 20A) / 390W (12V system, 30A)
Waterproof Level	IP32
Type	PWM
Rated Charge Current	10A / 20A / 30A
System Voltage	12V
Max PV Input Voltage	25V
Temperature Compensation	-3mV/°C/2V (Default)
Operating Temperature	-35°C to +55°C
Max Input Voltage	25V
Max Solar Input Current	10A / 20A / 30A
Max Load Current	10A / 20A / 30A
Protection	Overcharge Protection, Over-discharge Protection, Overload Protection, Short-circuit Protection, Reverse Polarity Protection
