Reolink RLN16-410 User Manual

Reolink PoE NVR
User Manual
49
latest firmware from Download Center to upgrade it.
Cause 3. The connection of the HDD is lost.
Solution:
Unplug the HDD then re-plug it.
Cause 4. The format of the HDD is wrong.
Solution:
Please format/init the HDD on the NVR monitor to try again.
Cause 5. NVR software issue.
Solution:
Please restore the NVR to default.
Cause 6. Defective HDD.
Solution:
Change another HDD to test whether it's the problem of a bad HDD.
7. NVR reboots itself automatically.
NVR reboots itself automatically may behave with any of the phenomena below:
①NVR reboots constantly.
②NVR reboots randomly (for example 2-3 times per day).
③Random gaps in the playback timeline. (All channels lost the recordings at the
same time, and the gap is greater than 30s.)
④A lot of "startup" on the NVR's log page.
Cause 1. UPS issue.
Solution:
If you use the UPS to power the NVR on, please plug the NVR directly to a wall
socket and have it run one or two day(s) then check if the NVR reboots. If the NVR
doesn't reboot, the issue should be on the UPS. Please make sure the UPS's
wattage is higher than the NVR adapter's wattage. If the NVR still reboots, please
refer to the following troubleshooting tips.
Cause 2. The HDD issue.
Solution:
Please unplug the HDD and have the NVR run one or two day(s), then check if the
NVR reboots.
Cause 3. The NVR and the cameras are both being grounded.
Solution:
Please unplug all the cameras from the NVR and have the NVR run on its own for
one or two day(s) and check if it still reboots. Please disable auto-reboot before you
run the test.

Reolink RLN16-410 Specifications

General

Number of users	20 user(s)
Maximum resolution	1920 x 1080 pixels
Video input channels	16 channels
Supported resolutions	1024x768, 1280x720, 1280x800, 1280x1024, 1440x900, 1920x1080
Operating system installed	Embedded LINUX
Product color	Black
eSATA ports quantity	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	1000 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	17
Supported network protocols	HTTP, HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Total installed storage capacity	3000 GB
Mobile operating systems supported	Android, iOS
Output current	2.5 A
Output voltage	48 V
AC input voltage	100-240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	HDMI, LAN (RJ-45)
Wi-Fi	No

Weight and Dimensions

Depth	260 mm
Width	330 mm
Height	45 mm
Weight	3000 g
