REPLIGEN XCell ATF Series

XCell
TM
ATF System with C410:V4B Controller User Guide
80
Profibus Input Signals (from Master to XCell™ ATF)
The following parameters can be sent from Profibus Master to command the XCell™ ATF.
Input Page 0
Profibus
Address
Tagname plc in DB31
PLC Address
Definition
Units
Data
type
Byte
#
Bit
#
Structure
Tagname in structure
0
0
InputPageX
PB_ATF_START_STOP
%DB31.DBX128.0
AFT Start/Stop
Byte
1
InputPageX
PB_ATF_Ack_Alarms
%DB31.DBX128.1
ATF Acknowledge Alarms
2
InputPageX
PB_Reset_Counters
%DB31.DBX128.2
Algorithm Performance Counters - Reset
3
InputPageX
PB_ATF_Control_Mode
%DB31.DBX128.3
Control Mode
4
InputPageX
PB_ATF_Slope_Enabled
%DB31.DBX128.4
Slope Function Enabled
5
%DB31.DBX128.5
6
%DB31.DBX128.6
7
%DB31.DBX128.7
1
InputPageX
RequestedDataPage
%DB31.DBW130
Requested Data Page
Int-16
2
3
InputPageX
SendingDataPage
%DB31.DBW132
Sending Data Page
Int-16
4
5
InputPage0
ATF_Connected_Bioreactor
%DB31.DBW134
ATF Connected Bioreactor
Int-16
6
7
InputPage0
SpareBytes1[0]
Byte
8
SpareBytes1[1]
Byte
9
SpareBytes1[2]
Byte
10
SpareBytes1[3]
Byte
11
SpareBytes1[4]
Byte
12
SpareBytes1[5]
Byte
13
SpareBytes1[6]
Byte
14
InputPage0
PFLOWSP
%DB31.DBD144
Pressure Flow Setpoint LPM
LPM
Real
15
16
17
18
InputPage0
PTIMESP
%DB31.DBD148
Pressure Flow Setpoint Time
SEC
Real
19
20
21
22
InputPage0
EFLOWSP
%DB31.DBD152
Exhaust Flow Setpoint LPM
LPM
Real
23
24
25
26
InputPage0
ETIMESP
%DB31.DBD156
Exhaust Flow Setpoint Time
SEC
Real
27
28
29
30
InputPage0
PRV1
%DB31.DBD160
Flow Regulator Setpoint
BAR/PSI
Real
31
32
33
34
InputPage0
PRV2
%DB31.DBD164
Exhaust Regulator Setpoint
BAR/PSI
Real
35
36
37
38
InputPage0
PV1
%DB31.DBD168
Flow Proportional Valve Setpoint
%
Real
39
40
41
42
InputPage0
PV2
%DB31.DBD172
Exhaust Proportional Valve Setpoint
%
Real
43
44
45
46
InputPage0
BatchName[0]
%DB31.DBB176
Batch Name
ASCII
47
BatchName[1]
%DB31.DBB177
ASCII
48
BatchName[2]
%DB31.DBB178
ASCII
49
BatchName[3]
%DB31.DBB179
ASCII
50
BatchName[4]
%DB31.DBB180
ASCII
51..63
Unused
