REPLIGEN XCell ATF Series

XCell
TM
ATF System with C410:V4B Controller User Guide
81
Input Page 1
Profibus Address
Tagname plc in DB31
PLC Address
Definition
Units
Data type
Byte #
Bit #
Structure
Tagname in structure
0
0
InputPageX
PB_ATF_START_STOP
%DB31.DBX128.0
AFT 1=Start/0=Stop
Byte
1
InputPageX
PB_ATF_Ack_Alarms
%DB31.DBX128.1
ATF Acknowledge Alarms
2
InputPageX
PB_Reset_Counters
%DB31.DBX128.2
Algorithm Performance Counters - Reset
3
InputPageX
PB_ATF_Control_Mode
%DB31.DBX128.3
Control Mode
4
InputPageX
PB_ATF_Slope_Enabled
%DB31.DBX128.4
Slope Function Enabled
5
6
7
1
InputPageX
RequestedDataPage
%DB31.DBW130
Requested Data Page
Int-16
2
3
InputPageX
SendingDataPage
%DB31.DBW132
Sending Data Page
Int-16
4
5
InputPage1
Model_Num_HMI
%DB31.DBW194
ATF Model Number
Int-16
6
0=ATF4, 1=ATF4MC, 2=ATF6, 3=ATF10lgcy &
4=ATF10
7
InputPage1
WATSP
%DB31.DBW196
Warning / Alarm Timer SP
MIN
Int-16
8
9
InputPage1
Bioreactor_Backpressure
%DB31.DBD198
Bioreactor Pressure
BAR/PSI
Real
10
11
12
13
InputPage1
Height_Differential
%DB31.DBW202
Height Differential
CM
Int-16
14
15
InputPage1
FDFOFST
%DB31.DBD204
Flow Driving Force Offset for Switching
BAR/PSI
Real
16
17
18
19
InputPage1
Press_Cycle_Delay_Time_SP
%DB31.DBW208
Pressure Cycle Delay Time SP
%
Int-16
20
21
InputPage1
Press_Cycle_Over_Time_SP
%DB31.DBW210
Pressure Cycle Over Time SP
%
Int-16
22
23
InputPage1
Pres_Cycl_PV_Step_Size
%DB31.DBD212
Pressure Cycle - PV Step Size - %
%
Real
24
25
26
27
InputPage1
EDFOFST
%DB31.DBD216
Exhaust Driving Force Offset for switching
BAR/PSI
Real
28
29
30
31
InputPage1
Vac_Cycle_Delay_Time_SP
%DB31.DBW220
Vaccum Cycle Delay Time SP
%
Int-16
32
33
InputPage1
Vac_Cycle_Over_Time_SP
%DB31.DBW222
Vaccum Cycle Over Time SP
%
Int-16
34
35
InputPage1
Exhs_Cycl_PV_Step_Size
%DB31.DBD224
Exhaust Cycle - PV Step Size
%
Real
36
37
38
39
InputPage1
P2_Pressure_Alarm_Hi_Hi_SP
%DB31.DBD228
P2 - Alarm SP - High High
BAR/PSI
Real
40
41
42
43
InputPage1
P2_Alarm_Hi_Hi_TMR_SP
%DB31.DBW232
P2 - Alarm Delay SP - High High
10MSEC
Int-16
44
45
InputPage1
P2_Pressure_Alarm_Lo_Lo_SP
%DB31.DBD234
P2 - Alarm SP - Low Low
BAR/PSI
Real
46
47
48
49
InputPage1
P2_Alarm_Lo_Lo_TMR_SP
%DB31.DBW238
P2 - Alarm Delay SP - Low Low
10MSEC
Int-16
50
51
InputPage1
PFLOWMAXSP
%DB31.DBD240
Max Pressure Flow Setpoint
LPM
Real
52
53
54
55
InputPage1
PFLOWMINSP
%DB31.DBD244
Min Pressure Flow Setpoint
LPM
Real
56
57
58
59
InputPage1
EFLOWMAXSP
%DB31.DBD248
Max Exhaust Flow Setpoint
LPM
Real
60
61
62
63
Unused
